HARDWARE
Bus Type:PCI Express X1
Card Type:Low Profile (SP bracket incl.)
Chipset ID:IRealtek RTL8125
Industry Standards:
IEEE 802.3bz (2.5GBASE-T)
IEEE 802.3ab (1000BASE-T)
IEEE 802.3u (100BASE-TX)
IEEE 802.3i (10BASE-TX)
Interface:RJ45 (Gigabit Ethernet)
Port Style:Integrated on Card
Port Numbers:1
PERFORMANCE
Compatible Networks:2.5G/1G/100Mbps/10Mbps
Auto MDIX:Yes
PXE:Yes
Full Duplex Support:Yes
Jumbo Frame Support:16K max.
CONNECTOR(S)
Connector Type(s):1-PCI Express x1 Male
External Ports:1-RJ45
System Requirements
Windows® XP Embedded, XP, Vista, 7, 8, 8.1, 10,11
Windows Server® 2003, 2008 R2, 2012, 2012 R2, 2016, 2019
Mac OS® 10.4 to 10.10
Linux LTS Versions Only
ENVIRONMENTAL
Humidity: 5~85% RH
Operating Temperature:0°C to 70°C (32°F to 158°F)
Storage Temperature:-20°C to 85°C (-4°F to 185°F)
Certification
CE、FCC、ROHS
