7-Port USB 2.0 Hub, TAA-Compliant

7-Port USB 2.0 Hub, TAA-Compliant

EMT SKU# MP8507

Product Overview

The 8507 is a TAA-compliant 7-port USB 2.0 hub designed for reliable USB expansion in government, enterprise, embedded, and OEM systems. It supports USB 2.0 data transfer rates up to 480Mbps, backward compatibility with USB 1.1/1.0 devices, over-current protection, optional external power input, and plug-and-play hot swap operation for practical system integration.

Key Features

  • High Speed USB 2.0 compliant, with supported data transfer rates up to 480 Mbps
  • Backwards compatible with USB 1.1/1.0 devices
  • Over current protection on each port
  • Includes optional external power adapter (5V/2A)
  • Plug and Play Hot Swap compatible
分類: 標籤:

HARDWARE

Bus Type: USB 2.0
Chipset ID: GENYSYS – GL850G
Interface: USB 2.0
Port Style: External Hub
Port Numbers: 10

PERFORMANCE

ESD Protection: +/-20kV (Air) +/-15kV (Contact)
Maximum Data Transfer Rate: 480 Mbps
Type and Rate: USB 2.0 – 480 Mbit/s

CONNECTOR(S)

1 x Terminal Block (2 Wire)
1 x DC Jack
1 x USB Type-C Power Input
1 x USB Type-C (Upstream, 9 pin) 2.0 Male
10 x USB Type-A (4 pin) USB 2.0 Female

System Requirements

Windows® XP Embedded, XP, Vista, 7, 8, 8.1, 10,11
Windows Server® 2003, 2008 R2, 2012, 2012 R2, 2016, 2019
Mac OS® 10.4 to 10.10
Linux  LTS Versions Only

ENVIRONMENTAL

Humidity: 5~85% RH
Operating Temperature: 0°C to 70°C (32°F to 158°F)
Storage Temperature: -20°C to 85°C (-4°F to 185°F)

Certification

CE、FCC、RoHS、REACH
