232R4-COMBO
232R4-COMBO：圖片 2

232R4-COMBO

MONTHERBOARD USB HEADER TO 4-PORT RS232/422/485 CRAD

  • 4-port USB to RS232/422/485 serial adapter.
  • USB Header to Straight-Through RS232 Serial.
  • Bus-Powered – no separate power supply or battery required.
  • Supports COM port retention.
  • Single chip USB to asynchronous serial data transfer interface.
  • UHCI/OHCI/EHCI host controller compatible.
  • USB 2.0 Full Speed compatible.
  • Synchronous and asynchronous bit bang interface options with RD# and WR# strobes.
  • FIFO receive and transmit buffers for high data throughput.
分類: 標籤: , , ,

HARDWARE

Bus Type: USB 2.0
Card Type: Low Profile (SP bracket incl.)
Chipset ID: FTDI – FT232RL
Interface: Serial
Port Style: Dongle (Included)
Port Numbers: 4

PERFORMANCE

FIFO: 32 Bytes
Max Baud Rate: 921.6 Kbps
Serial Protocol: RS-232/422/485

CONNECTOR(S)

1 x IDC (4 pin, Motherboard Header) Female
4 x DB-9 (9 pin, D-Sub) Male

System Requirements

Windows® XP Embedded, XP, Vista, 7, 8, 8.1, 10,11
Windows Server® 2003, 2008 R2, 2012, 2012 R2, 2016, 2019
Mac OS® 10.4 to 10.10
Linux  LTS Versions Only

ENVIRONMENTAL

Humidity: 5~85% RH
Operating Temperature: 0°C to 70°C (32°F to 158°F)
Storage Temperature: -20°C to 85°C (-4°F to 185°F)

Certification

CE、FCC、RoHS、REACH
